High quality SA516 GR.70 N 2:1 Semi Elliptical Head

Haipei Industry High quality SA516 GR.70 N 2:1 Semi Elliptical Head

Haipei Industry proudly presents its premium line of Ellipsoidal Heads 2:1, an essential component in the construction of pressure vessels and tanks designed to meet the demanding requirements of various industrial applications. With a focus on quality, precision, and compliance with international standards, our elliptical tank heads deliver superior performance and adaptability.

Technical Specifications

*Straight flange dimensions are subject to feasibility studies based on De and thickness.

Product Features and Benefits

1. Versatile Applications

• Ideal for medium-pressure vessels such as air receivers and liquefied petroleum gas tanks.

• Widely used in industries requiring safe and durable pressure containment solutions.

2. Optimized Design

• Depth of dish equals one-quarter of the head’s internal diameter (ID), ensuring efficient stress distribution.

• The inside height combines the depth of the dish and the straight flange, offering tailored configurations for specific requirements.

3. Economical Solution

• Reduced metal thickness compared to other head types, lowering material costs without compromising structural integrity.

4. Customization

• Manufactured using cold or hot forming techniques to accommodate various dimensions, materials, and thicknesses.

• Every request undergoes a comprehensive feasibility study to ensure the highest quality and suitability.

5. Compliance with Standards

• ASME-compliant 2:1 elliptical flanged and dished heads meet the rigorous requirements for unfired pressure vessels.

Why Choose Haipei Industry?

• Expertise and Innovation: Decades of experience in producing elliptical tank heads for diverse pressure vessel environments.

• Precision Engineering: Advanced fabrication processes ensure precise dimensions and durability.

• Customer-Centric Approach: Tailored solutions for every project, with dimensions beyond indicated ranges evaluated for feasibility.

• High-Quality Materials: Premium-grade materials to ensure long-lasting performance and safety.

Technical Insights

The Ellipsoidal Head 2:1 is characterized by its unique geometry, consisting of a rotating ellipsoidal sphere combined with a cylindrical straight section. This design provides optimal strength and reduces material thickness requirements, making it an efficient and reliable choice for medium-pressure applications. The dish radius is approximately 90% of the diameter, while the knuckle radius is about 17%, ensuring balanced stress distribution and robust structural integrity.

Get in Touch

For more information or to discuss your specific requirements, contact Haipei Industry. Our team of experts is ready to assist you with customized solutions, ensuring your pressure vessel needs are met with precision and reliability.

Company information

Haipei industry can produce all types of dished ends heads. They can be manufactured from a number of steel types including pressure vessel and boiler quality, chrome moly and stainless steel. The company also offers 2:1 semi ellipsodial, hemispherical petals, torispherical ends as well as conical knuckled sections.

Haipei industry company is a leading producer of various types of dished heads, cones, and other special pressed products in different materials grades like Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations.

Our Services

We offer our products in the following materials:

Carbon Steel: SA36, SA516-70, SA387 Grade 5 Class 2 (Forming Only), SA285 Grade C (Forming Only)

Stainless Steel: SA240T304/304L, SA240T316/316L, SA240T304H (Forming Only), SA240T904/904L (Forming Only)

Copper: O-Temper Material (Forming Only)

Aluminum: O-Temper Material (Forming Only)

Quality assurance
Quality is the most important aspect of strength.We will make the material from the material to the end of the monitoring, making sure that each part can be of high quality according to the regulations.Each program will be monitored to ensure any errors in the manufacturing process.
Competitive price guarantee
With years of experience, we can offer our customers the most competitive prices.At the same time, as a powerful factory, we can offer customers more favorable prices than other factories.
Delivery time guarantee
We will strictly control the manufacturing schedule to ensure punctual delivery.It can satisfy the customer's time schedule and ensure the continuous production of customers.

Packaging & Shipping

Carbon steel Hemispherical spherical head for Industrial hot blast stove

1. Iron Frame2. Wooden Box3. Iron pallet4.Wooden pallet.5.Professional fixation6. Curstomed requirment

Haipei Industry High quality SA516 GR.70 N 2:1 Semi Elliptical Head 4600mm Diameter 80mm Thickness from China, China's leading SS316L Elliptical Dish Head Product ASTM A516 Grade 70 and ASME SA516 Grade 70 Carbon Steel Plate for Boilers and Pressure Vessels ASME 2:1 Semi Elliptical Standard Flanged & Dished Flared Dished ASME Conical Heads ASME SA516 GR.70 CARBON STEEL DISH HEAD HEMISPHERICAL END CAP Semi-Elliptical 2:1 heads and the approximate delivery time of non- stock sizes. This chart applies only to heads made from SA 516 Grade 70 mate- rial ASTM ASME Semi Ellipsoidal Head 2: 1 Boiler End Bottom for Pressure Vessel 2:1 Head Dishhead Dishend Dish Head Dish End Type of Equipment : Pressure Vessel ID 1850mm* 50SF * 35Min THK A/F Material specification : SA516-70N Whatsapp:+8618264838918 [email protected]

Haipei Industry ASME 2:1 Semi-Elliptical Head in SA516-70 fabricated segmented domes, hemispheres, 2:1 elliptical, and ASME flanged & dished heads when projects call for larger pressing capacities. An ASME 2:1 semi-elliptical head in SA516-70 is a widely used carbon steel pressure vessel closure. The 2:1 ratio means the head's depth is exactly one-quarter of its inner diameter, while SA516-70 provides excellent tensile strength (70 ksi minimum) and is the industry standard for moderate and lower-temperature service SA516 GR70 Elliptical Dished Heads And Steel Plates We are the professional manufacturer of ASME SA516 Gr. 70 ,SA-516-70N Dished Elliptical Head End Caps,DIN 28013 Ellipsoidal heads in China. 2:1 elliptical heads.
